Meet Kollmorgen at ProMat 2023

06 Mar 2023

We are excited to announce that Kollmorgen is back at ProMat 2023. Meet us in booth N8522 to discover how you can automate your fleet with NDC Solutions.

Discover vehicle automation powered by 5G at MWC Barcelona 2023

27 Feb 2023

Join Kollmorgen and ek robotics in conjunction with Ericsson at Mobile World Congress (MWC) Barcelona 2023 on February 27 - March 2, one of the largest events for the connectivity ecosystem, where technology, community and commerce converge. Together they will demonstrate how you can benefit from automated guided vehicle (AGV) and mobile robot applications powered by 5G at Ericsson’s booth in Hall 2 Stand 2O60.

Kollmorgen launches the advanced P8000 series with the new P80630-SDN Stepper Drive

24 Jan 2023

RADFORD, VA., 1/24/2023 — Kollmorgen, a global leader in motion control systems, today announced the new P80630-SDN stepper drive. Customers can now benefit from features such as smoothness, precision and torque across the full speed range in a significantly more compact package that enables smaller, lighter, more versatile machines. Kollmorgen will also be introducing additional stepper drives and features in the coming months, building upon the new, flagship P8000 stepper drive platform.

Front AGV Joins Forces With Kollmorgen to Create Top-Level AGVs

09 Dec 2022

Front AGV, a Swedish integrator and designer of automated guided vehicles (AGVs), joins forces with Kollmorgen Automation to create top-level AGV solutions. Front AGV is part of 3BUTTON GROUP AB, an automation group specialized in user-friendly and advanced robotic solutions for the consumer, food and automotive industries. The solutions cover a range of processes in the manufacturing line; from machine tending, assembly and labeling, to picking, packing, and palletizing.

Kollmorgen forms strategic partnership with ARME

13 Oct 2022

The Spanish Association of Mobile Robotics (ARME) and Kollmorgen Automation have entered into a strategic partnership to offer high quality integration solutions for AGVs and mobile robots, based on the NDC8 platform. With this union, ARME aims to strengthen the position of AGVs and mobile robots at the Spanish market.

Join Kollmorgen at Digital X 2022

07 Sep 2022

Join us at Digital X 2022, the world exhibition of digitalization, in the heart of Cologne 13-14 September. Together with Cradlepoint (part of Ericsson) we will demonstrate that our world-leading control systems for AGVs and mobile robots, including fleet management system, software tools for commissioning and navigation capabilities, can run on a 5G network, for a stable and future proof intralogistics solution in line with Industry 4.0.

Kollmorgen forms collaboration with Vanderlande

10 Aug 2022

Vanderlande has selected Kollmorgen NDC Solutions as a technology and service partner for their automated guided vehicle (AGV) applications. Based on Toyota Material Handling forklifts equipped with the Kollmorgen NDC Solutions technology, Vanderlande aims to strengthen and grow their portfolio of complete logistic and warehouse solutions.

Kollmorgen to Introduce New TMB2G Robot-Ready Frameless Servo Motors at Automate 2022 (Booth #4149)

06 May 2022

Kollmorgen will exhibit their next-generation TBM2G series of frameless servo motors at the 2022 Automate Show, June 6 - 9, in Detroit, MI. Kollmorgen will also speak on the topic of Improving Robot Efficiency Through Permanent Magnet Motor Design and Selection at the breakout session on the afternoon of June 8.

Kollmorgen introduces a new generation of robot-ready frameless servo motors

14 Apr 2022

After years in development, the TBM2G frameless motor line is here and ready to take your robot, medical device, industrial machine or vehicle to a new standard of performance. Learn what these compact frameless motors are capable of delivering.

Meet us at LogiMAT 2022

09 Mar 2022

We are excited to announce that Kollmorgen NDC Solutions is back at LogiMAT 2022. These last two years have been exceptionally busy for us. The rapid growth of our global partner base and their applications, demonstrates the value that NDC Solutions continuously delivers. We look forward to sharing the latest development news and how our industry leading NDC Solutions technology enables our partners to build exceptional autonomous vehicle applications – by delivering advanced software and hardware for navigation and controls, together with extensive business services.
