Centurion LSM Series

LSM low inertia servomotors offer very high torque in a compact package, providing a rugged, cost-effective solution for applications such as smart conveyors, packaging machinery, punch press/material feeding, robotic pick and place, high duty cycle applications and more. High-energy neodymium rare earth permanent magnet rotors deliver high acceleration while the unique stator assembly provides superior heat transfer for reliable operation.

Contact Us
1-540-633-3545



  • High energy neodymium magnet rotors provide high acceleration/deceleration in minimum package size
  • Eight pole motor design for high torque and low cogging
  • Temperature sensors built into windings allow intelligent shut down in overload conditions
  • Unique stator design provides optimal thermal transfer to handle high hit-rate, demanding applications
  • High radial load rating allows use of direct mount pinions and belt pulleys for cost-effective application
  • Standard cable sets simplify machine design, build and commissioning
  • Flexible feedback options include incremental encoder standard, with high resolution and multi-turn absolute encoder available
  • IEC form factor simplifies machine design by allowing use of standard gearboxes and mounting plates
  • IP65 packaging ensures reliable operation in harsh environments
  • Maintenance-free design
  • UL, cUL and CE Mark allow worldwide application





230 Volt LSM Motors





Motor Model

LSM54-3-602

LSM63-6-602

LSM63-12-602

LSM75-21-602

LSM75-29-602

Mechanical Data

Rotor Moment of Inertia

lb-in-s2

kg-m2

lb-in-s2

kg-m2

lb-in-s2

kg-m2

lb-in-s2

kg-m2

lb-in-s2

kg-m2

.00003

.0000029

.00011

.000013

.00017

.00002

.00029

.000033

.00039

.000044

Motor Net Weight

lb

kg

lb

kg

lb

kg

lb

kg

lb

kg

1.5

.7

3.1

1.4

4.0

1.8

6.8

3.1

8.6

3.9

Winding Data

KT (Nm/Amp)

.35

.35

.36

.42

.40

KEVoltage Constant2(V/kRPM)

43

43

43

49

49

Winding Resistance Ph to phase @ 25°C

30.29

8.49

3.68

2.26

1.32

Winding Inductance Phase to phase (mH)

57.5

26.2

13.0

17.9

12.4



460 Volt LSM Motors






Motor Model

LSM100-22-454

LSM100-35-454

LSM100-46-454

LSM130-78-454

LSM130-102-304

Mechanical Data

Rotor Moment of Inertia

lb-in-s2

kg-m2

lb-in-s2

kg-m2

lb-in-s2

kg-m2

lb-in-s2

kg-m2

lb-in-s2

kg-m2

.001

.00011

.0013

.000144

.0015

.00017

.0036

.00041

.0049

.00055

Motor Net Weight

lb

kg

lb

kg

lb

kg

lb

kg

lb

kg

9.3

4.2

11.7

5.3

13.9

6.3

22

10.0

26

11.8

Winding Data

KT(Nm/Amp)1

.82

.86

.88

.88

1.28

KE (V/KRPM) Voltage Constant

99

103

106

107

154

Winding Resistance Ph to phase @ 135°C

10.7

5.9

3.9

1.68

2.2

Winding Inductance Phase to phase (mH)

25.8

16.8

12.44

8.46

12.4





Motor Model

LSM165-119-454

LSM165-173-304

LSM165-221-454

LSM215-301-304

LSM215-451-204

LSM215-589-204

Mechanical Data

Rotor Moment of Inertia

lb-in-s2

kg-m2

lb-in-s2

kg-m2

lb-in-s2

kg-m2

lb-in-s2

kg-m2

lb-in-s2

kg-m2

lb-in-s2

kg-m2

.0081

.00092

.0113

.00128

.0146

.00165

.0376

.00425

.0531

.0060

.0681

.0077

Motor Net Weight

lb

kg

lb

kg

lb

kg

lb

kg

lb

kg

lb

kg

35.7

16.2

41.2

18.7

46.3

21.0

68.4

31.0

84.9

38.5

100.3

45.5

Winding Data

KT(Nm/Amp)1

.87

1.29

.91

1.22

1.84

1.84

KE(V/KRPM) Voltage Constant

105

1.56

109

147

222

222

Winding Resistance Ph to phase @ 135°C

0.76

0.98

0.33

0.38

0.50

0.31

Winding Inductance Phase to phase (mH)

6.68

9.6

3.6

6.94

10.0

7.4





1Peak value of per phase sine wave Amps

2Peak value of sinusoidal phase to phase Volts
