Features

• Wide output range from 1.8 to 108 Amps RMS/phase, continuous
• Separate control power and line power inputs enable diagnostics and feedback tracking even when line voltage is off
• Wide line voltage range: 100 to 240 VAC 1-phase input (230 volt drive) or 200 to 480VAC 3-phase input (460 volt drive)
• Available on-board digital MMC controller for control of up to 16 axes
• Compatible with incremental encoder, resolver, sine encoder, EnDat 2.1 sine encoder, BiSS sine encoder, and Comcoder feedback
• All setup and tuning parameters are saved in nonvolatile memory on the drive and can also be saved to disk
• Velocity loop bandwidth up to 400 Hz
• Advanced speed control algorithms for superior control
• CE Marked; UL and cUL Listed
• External active shunt available (230 volt drive) or external passive shunt available (460 volt drive)
• Phase-to-phase and phase-to-ground short circuit protection

Benefits

• Autotune feature automatically detects load inertia for simple servo tuning
• Digital design enables reliable, repeatable setup
• High-bandwidth control loops accommodate the changing load conditions found in industrial applications
• Plug-and-play cable sets and built-in power supply are engineered for easy installation and noise-free operation
• Short-circuit protection and over-voltage, over-current, over-temperature detection to protect the drive, motor and application
• Optically isolated I/O for noise immunity
• Simple setup, programming, diagnostics and troubleshooting using Windows-based PicPro® software and real-time software oscilloscope
